Quick-Turn Prototypes & Production PCBs
2–120 Layers | High-Speed & Complex PCB Expertise
As Fast As 8-Day Delivery For 12–20 Layer PCBs
20+ Years Of PCB Manufacturing Experience
Min. Line/Space: 30/30 μm
Aspect Ratio up to 75:1
Standard FR4 & High-Speed Materials Always in Stock
Advanced Equipment & Class 1000 Cleanroom
| Item | Process Parameters |
|---|---|
| Layer Count | 2-120 Layers |
| Board Thickness | 0.3-10mm |
| Max. Board Size | 660 x 1250mm |
| Mechanical Drill Size | ≥0.11mm |
| Laser Drill Size | 0.06mm |
| HDI Types | 1+N+1, 2+N+2, 3+N+3, Any-layer HDI |
| Finished Board Aspect Ratio | 75:1 |
| Inner-layer Registration | 4mil |
| Min. Line Width | 30/30μm |
| Impedance Tolerance | ±5% |
| Dimensional Tolerance | ±0.05mm |
| Bow & Twist / Warpage | ≤0.5% |
| Base Materials / Laminates | Standard FR4, M4/M6/M7/M8, IT958G/968/988GSE, S7439C, TU883+/933+, TU862HF, EM890K, EM892K2, RO4350, etc. |
| Surface Finishes | HASL, Lead-Free HASL, ENIG, Immersion Tin, Immersion Silver, Plated Gold, ENEPIG, OSP, ENIG+OSP |
| Special Technologies | Buried/Blind Vias, Step Grooves, Metal Core PCB (MCPCB), Embedded Resistors/Capacitors, Hybrid Press-fit (Mixed-Material Lamination), Rigid-Flex PCB, Back-drilling, Gold Fingers, POFV (Plated Over Filled Vias), Selective Gold Plating |
| Layer Count | Prototype (Rush) | Prototype (Standard) | Mass Production |
|---|---|---|---|
| 2-Layer | 48 Hours | 5 Days | 9 Days |
| 4-Layer | 3 Days | 6 Days | 10 Days |
| 6-Layer | 3 Days | 6 Days | 11 Days |
| 8-Layer | 4 Days | 7 Days | 11 Days |
| 10-Layer | 4 Days | 7 Days | 12 Days |
| 12-Layer | 5 Days | 8 Days | 12 Days |
| 14-Layer | 5 Days | 8 Days | 12 Days |
| 16-Layer | 5 Days | 8 Days | 12 Days |
| 18-Layer | 6 Days | 8 Days | 12 Days |
| 20-Layer | 6 Days | 8 Days | 12 Days |
| 22-Layers | 8 Days | 12 Days | 16 Days |
| 26-Layers | 8 Days | 12 Days | 16 Days |
| 28-Layers | 8 Days | 12 Days | 16 Days |
| 30-Layers | 8 Days | 12 Days | 16 Days |
| 32-Layers | 10 Days | 14 Days | 18 Days |
| 34-Layers | 10 Days | 14 Days | 18 Days |
